Diffusion-locking caps (DiffLok)
DiffLok™ caps sit on both ends of a sorbent tube throughout the entire analytical sequence, in all Markes’ automated thermal desorption instruments. Their patented design prevents loss of sample and ingress of contaminants onto the tube, and avoids the need for complex robotics to cap and uncap tubes. DiffLok caps are available in stainless and inert-coated stainless steel.
Read the full story behind Diffusion-locking technology in our blog.
- Preserve sample integrity by preventing analyte loss and contamination
- Ensure reproducible results during analysis
- Push-fit for ease of use
Product List
Showing 14/14 results
DiffLok cap- inert, 1/4 inch ID- 10 pack
Product Code
C-DLS10
DiffLok cap- inert, 1/4 inch ID- pack of 100
Product Code
C-DL1S0
DiffLok cap- stainless steel, 1/4 inch ID- 10 pack
Product Code
C-DL010
DiffLok cap- stainless steel, 1/4 inch ID- pack of 100
Product Code
C-DL100
DiffLok caps (one stainless steel- one inert), 1/4 inch ID- 10 pack pairs
Product Code
C-DLP10
DiffLok caps (one stainless steel- one inert), 1/4 inch ID- pack of 100 pairs
Product Code
C-DL1P0
High-flow DiffLok cap- stainless steel, 1/4 inch ID- for use with SafeLok tubes- 10 pack
Product Code
C-DL010-HF
High-flow DiffLok cap- stainless steel, 1/4 inch ID- for use with SafeLok tubes- pack of 100
Product Code
C-DL100-HF
DiffLok cap- inert, 6 mm ID (for DAAMS) - 10 pack
Product Code
C-DLS10-XZ
DiffLok cap- stainless steel, 6 mm ID (for DAAMS) - 10 pack
Product Code
C-DL010-XZ
DiffLok caps (one stainless steel- one inert), 6 mm ID (for DAAMS) - 10 pack
Product Code
C-DLP10-XZ
DiffLok cap- inert, 6 mm ID (for DAAMS) - pack of 100
Product Code
C-DL1S0-XZ
DiffLok cap- stainless steel, 6 mm ID (for DAAMS) - pack of 100
Product Code
C-DL100-XZ
DiffLok caps (one stainless steel- one inert), 6 mm ID (for DAAMS) - pack of 100 pairs
Product Code
C-DL1P0-XZ
Overview
DiffLok caps contain a long/narrow helical flow path, which slows the rate of diffusion to a point where it becomes negligible. However, once pressure is applied in the analytical system (or via a pump), the tube performs as an uncapped tube.
DiffLok caps are available for industry-standard tubes (ID 1/4 inch) and 4½ inch DAAMS tubes (ID 6mm).
When working with inert tubes, only one inert cap is required on the sampling end of the tube; the other end can be stainless steel, as it is not in the flow path of the sample. Replacement O-rings are available for routine maintenance.
40 caps (20 stainless steel and 20 inert-coated stainless steel) ship with each automated instrument from Markes.
DiffLok caps are also used with an MTS-32 (multi-tube sequencer) to prevent loss of sample, ingress of contaminants and diffusive effects when undertaking low-flow sampling. For less experienced users, they can also be used in combination with SafeLok inserts in place of long-term storage caps.
Part numbers:
C-DL010 - C-DL010-HF - C-DL010-XZ - C-DL100 - C-DL100-HF - C-DL100-XZ - C-DL1P0 - C-DL1P0-XZ - C-DL1S0 - C-DL1S0-XZ - C-DLP10 - C-DLP10-XZ - C-DLS10 - C-DLS10-XZ
